CPLS
Induction motors for variable frequency from 95 Nm to 2900 Nm
Advantages
- Small dimensions thanks to its high specific output power (interchangeable with DC motors)
- Possibility of working at high speed in test bench applications
- Economical: lower maintenance costs, competitive price of induction motor and drive assembly
- Wide speed range for work at constant power
Main Characteristics
| Frame size | mm | 112 to 250 |
|---|---|---|
| Number of poles | 4 | |
| Rated torque | N.m | 95 to 2900 |
| Speed | rpm | 0 to 10,000 |
| Voltage | V | 320 - 340 - 360 - 380 - 400 - 440 - 480 |
| Ingress protection | IP | 23 |
| Cooling | IC06: forced ventilation unit | |
| Options | Brake |
