BLDC - Low Voltage Solutions
28/48 VDC
055 to 115 motor frames
BLDC motors are low voltage, brushless DC motors with frame sizes from 55mm to 115mm.
These compact motors offer high energy efficiency for applications requiring extended battery life. Unlike conventional DC motors, BLDC motors are maintenance-free thanks to their brushless design.
For optimal performance, each motor is customized to the application and we work closely with our customers to tailor products to their specific requirements. Our expertise in this field means that we can engineer solutions for a wide range of applications including:
- E-mobility (electric vehicles)
- AGV (Automated Guide Vehicle)
- Hoisting
- Door opening
- Printing
- Power generation
Advantages
Custom-built solution
- Range of options : brakes, gearboxes, hall effect sensors, connectors
- Special shafts and flanges
- Dimensions, interfaces and electrical connections adapted to the application
Compact with high power density
- Ideal for applications where space is restricted and mobility is needed
High motor efficiency
- Extended battery life
Maintenance-free
- Advantage compared to traditional DC motors
- Potted stator for increased durability and resistance to harsh environments
Main Characteristics
Motor Type 24/48 VDC | Frame Size (mm) | Rated Torque (N.m) | Feedback device | ||
2000 rpm | 3000 rpm | 6000 rpm | |||
SMV51 | 55 | - | 0.4 to 1.3 | 0.3 to 0.7 | R, E, S |
SMV62 | 67 | - | 0.8 to 2.5 | 0.6 to 2.3 | R, E, S |
SMV84 | 89 | 2.4 to 4.9 | 2.1 to 4.5 | 1.9 to 4.2 | R, E, H, S |
SMV107 | 115 | 3.5 to 9.0 | 3.0 to 8.0 | - | R, E, H, S |
