DFS SERIES
55 kW to 540 kW
400 V | 690 V
For many drive users, designing and building a high power drive cubicle requires extensive in house engineering expertise that they do not have.
The DFS Drive is a pre-assembled, ready to install drive cubicle system designed for use in high power applications where energy saving and high ingress protection are key. With fast, easy installation, plant availability is maximised with virtually zero requirement from your engineering resource.
DFS Highlights
✓ Ready to use
✓ Fast turnaround
✓ Easy set-up
✓ Rugged, reliable drive systems
Cubicle Options:
| Enclosure rating | A = IP23 (Standard) C = IP54 – Air inlet grill filters |
| Electrical environment | EMC filter to meet generic emission IEC 61000-6-4 or operate in the First Environment Remove internal EMC filter for use on un earthed supplies Remove MOV protection for use on un earthed supplies |
| AC Input Disconnect | A – Main switch with undervoltage release coil 230 VAC (MN) B – Main switch with undervoltage release coil 24 VAC (MN) C – Main switch with shunt trip voltage release coil 230 VAC (MX) D – Main switch with shunt trip voltage release coil 24 VAC (MX) 2 x auxiliary contacts on main switch – supply and wiring |
| Emergency stop push button door mounted | For integration in your control system |
| Cubicle Options | Cabinet temperature-controlled roof fan Plinth 200mm. Standard plinth is 100mm Alternative 180 ° door hinges for improved access Cylinder lock with key for extra cubicle security |
| Energy Monitoring | A – kWh meter Conventional (IP54) with current transducers (non MID) B – kWh meter Modbus RTU with current transducers (non MID) C – kWh meter Profibus (400 V SUPPLY ONLY) with current transducers (non MID) D – kWh meter Ethernet with current transducers (non MID) kWh meter pulse contacts in combination with A, B, C OR D kWh meters |
| 24 V back-up power | Supply wiring installed for external 24V backup power supply |
| Additional Cubicles | A – Integrated 400 mm empty cubicle with plinth, cable plates INCLUDING mounting plate For your system equipment B – Integrated 400 mm empty cubicle with plinth, cable plates and WITHOUT mounting plate For your installation cable management |
| Packaging | A – Integrated 400 mm empty cubicle with plinth, cable plates INCLUDING mounting plate For your system equipment B – Integrated 400 mm empty cubicle with plinth, cable plates and WITHOUT mounting plate For your installation cable management |
